NoFloods TubeBarriers URBAN Products
NoFloods URBAN Models
Single Tube
The NoFloods Single Tube is primarily used when additional height or structural support is required. It is not designed to be deployed as a standalone barrier. Instead, it can be installed as a third tube on top of the NoFloods Twin Tube System, instantly increasing the barrier’s height and water retention capacity.
| Product Name | 10 m | 15 m | 50 m | 100 m | 200 m |
|---|---|---|---|---|---|
|
NoFloods PRO Single Tube 60 |
8kg |
12kg |
40kg |
80kg |
160kg |
|
Product ID |
MB-1U32 |
MB-1U42 |
MB-1U72 |
MB-1U82 |
MB-1U92 |
|
NoFloods PRO Single Tube 125 |
16kg |
24kg |
80kg |
160kg |
320kg |
|
Product ID |
MB-1U33 |
MB-1U43 |
MB-1U73 |
MB-1U83 |
MB-1U93 |
Discover the full capabilities of the NoFloods TubeBarrier URBAN in our catalogues, where you’ll find detailed specifications, installation guidance, and real-world examples of how this innovative system delivers sustainable, reusable flood protection without compromising aesthetics or accessibility.
Deployment Process
The deployment principles for both the NoFloods Pro and Urban solutions are fundamentally the same, ensuring a straightforward and efficient setup process. Both systems are rolled out on-site and filled with water to create a stable flood barrier.
Arrival & Site Inspection
Inspect the deployment site upon arrival. NoFloods Barriers can be deployed directly from a trailer, small truck, storage bag, or deployment box.
Barrier Deployment
Unroll or pull out the NoFloods Barrier at the
desired location along the intended flood path.
Connection Setup
Adjust and securely tighten the end caps.
Filling the Tubes
Fill directly with water.
Once filled, the barrier is ready for operation.
Emptying & Disassembly
Disassembly is quick and straightforward. Release
water in a controlled manner, then roll in the tubes. For longer sections, we recommend using the NoFloods Hydraulic Winch for efficient retrieval.
